10.1007/s40204-014-0020-0

Electrospun poly(caprolactone)-elastin scaffolds for peripheral nerve regeneration

HTML PDF
  • Katelyn E. Swindle-Reilly*1,
  • Chinmay S. Paranjape2,
  • Cheryl A. Miller1,
  1. Department of Biomedical Engineering, Saint Louis University, St. Louis, MO, 63103, US
  2. Department of Chemical and Biomolecular Engineering, University of Pennsylvania, Philadelphia, PA, 19104-6315, US
Cover Image

Published in Issue 2014-02-21

How to Cite

Swindle-Reilly, K. E., Paranjape, C. S., & Miller, C. A. (2014). Electrospun poly(caprolactone)-elastin scaffolds for peripheral nerve regeneration. Progress in Biomaterials, 3(1 (June 2014). https://doi.org/10.1007/s40204-014-0020-0
Crossref
Scopus
Google Scholar
Europe PMC

Abstract

Abstract Peripheral nerve regeneration can be enhanced by chemical and mechanical cues for neurite growth. Aligned and randomly oriented electrospun nanofibers of poly(ε-caprolactone) (PCL) or a blend of PCL and elastin were fabricated to test their potential to provide contact guidance to embryonic chick dorsal root ganglia for peripheral nerve regeneration. Scanning electron microscopy was used to analyze the fiber diameter. Fiber diameter was found to be significantly smaller when elastin was incorporated into the scaffold (934 ± 58 nm for PCL and 519 ± 36 nm for PCL:elastin). After 24 h in culture, there was preferential cell attachment and neurite extension along the fibers of the elastin-containing scaffolds (average neurite extension 173.4 ± 20.7 μm), indicating that the presence of elastin promotes neurite outgrowth on electrospun scaffolds.

Keywords

  • Electrospinning,
  • Elastin,
  • PCL,
  • Peripheral nerve regeneration,
  • Dorsal root ganglia,
  • Nanofibers
HTML PDF

References

  1. Boland et al. (2004) Electrospinning collagen and elastin: preliminary vascular tissue engineering (pp. 1422-1432) https://doi.org/10.2741/1313
  2. Buttafoco et al. (2006) Electrospinning of collagen and elastin for tissue engineering applications (pp. 724-734) https://doi.org/10.1016/j.biomaterials.2005.06.024
  3. Chew et al. (2008) The effect of the alignment of electrospun fibrous scaffolds on Schwann cell maturation (pp. 653-661) https://doi.org/10.1016/j.biomaterials.2007.10.025
  4. Corey et al. (2007) Aligned electrospun nanofibers specify the direction of dorsal root ganglia neurite growth (pp. 636-645) https://doi.org/10.1002/jbm.a.31285
  5. Desai et al. (2008) Morphological and surface properties of electrospun chitosan nanofibers (pp. 1000-1006) https://doi.org/10.1021/bm701017z
  6. Ghasemi-Mobarakeh et al. (2008) Electrospun poly(ε-caprolactone)/gelatin nanofibrous scaffolds for nerve tissue engineering (pp. 4532-4539) https://doi.org/10.1016/j.biomaterials.2008.08.007
  7. Griffin and Hoffman (1993) Degeneration and regeneration in the peripheral nervous system (pp. 361-376)
  8. Jeffries and Wang (2012) Biomimetic micropatterned multi-channel nerve guides by templated electrospinning (pp. 1571-1582) https://doi.org/10.1002/bit.24412
  9. Jha et al. (2011) Two pole air gap electrospinning: fabrication of highly aligned, three dimensional scaffolds for nerve reconstruction 7(1) (pp. 203-215) https://doi.org/10.1016/j.actbio.2010.08.004
  10. Kim et al. (2008) Nanofibrous matrices of poly(lactic acid) and gelatin polymeric blends for the improvement of cellular responses (pp. 25-32) https://doi.org/10.1002/jbm.a.31677
  11. Koh et al. (2008) Enhancement of neurite outgrowth using nano-structured scaffolds coupled with laminin (pp. 3574-3582) https://doi.org/10.1016/j.biomaterials.2008.05.014
  12. Li et al. (2005) Electrospun protein fibers as matrices for tissue engineering (pp. 5999-6008) https://doi.org/10.1016/j.biomaterials.2005.03.030
  13. Li et al. (2006) Co-electrospun poly(lactide-co-glycolide), gelatin, and elastin blends for tissue engineering scaffolds (pp. 963-973) https://doi.org/10.1002/jbm.a.30833
  14. Li et al. (2006) Fabrication and characterization of six electrospun poly(alpha-hydroxy ester)-based fibrous scaffolds for tissue engineering applications (pp. 377-385) https://doi.org/10.1016/j.actbio.2006.02.005
  15. Matthews et al. (2002) Electrospinning of collagen nanofibers (pp. 232-238) https://doi.org/10.1021/bm015533u
  16. McClure et al. (2008) Cross-linking electrospun polydioxanone-soluble elastin blends: material characterization 3(1) (pp. 1-10)
  17. Neal et al. (2009) Laminin nanofiber meshes that mimic morphological properties and bioactivity of basement membranes 15(1) (pp. 11-21) https://doi.org/10.1089/ten.tec.2007.0366
  18. Neal et al. (2012) Alignment and composition of laminin-polycaprolactone nanofiber blends enhance peripheral nerve regeneration (pp. 406-423) https://doi.org/10.1002/jbm.a.33204
  19. Panseri et al. (2008) Electrospun micro- and nano-fiber tubes for functional nervous regeneration in sciatic nerve transections https://doi.org/10.1186/1472-6750-8-39
  20. Powell and Boyce (2008) Fiber density of electrospun gelatin scaffolds regulates morphogenesis of dermal-epidermal skin substitutes 84A(4) (pp. 1078-1086) https://doi.org/10.1002/jbm.a.31498
  21. Prabhakaran et al. (2013) Electrospun aligned PHBV/collagen nanofibers as substrates for nerve tissue engineering 110(10) (pp. 2775-2784)
  22. Reed et al. (2009) Composite tissue engineering on polycaprolactone nanofiber scaffolds (pp. 505-512) https://doi.org/10.1097/SAP.0b013e31818e48bf
  23. Schnell et al. (2007) Guidance of glial cell migration and axonal growth on electrospun nanofibers of poly-ε-caprolactone and a collagen/poly-ε-caprolactone blend (pp. 3012-3025) https://doi.org/10.1016/j.biomaterials.2007.03.009
  24. Sell et al. (2010) The use of natural polymers in tissue engineering: a focus on electrospun extracellular matrix analogues (pp. 522-553) https://doi.org/10.3390/polym2040522
  25. Stitzel et al. (2006) Controlled fabrication of a biological vascular substitute (pp. 1088-1094) https://doi.org/10.1016/j.biomaterials.2005.07.048
  26. Um et al. (2004) Electro-spinning and electro-blowing of hyaluronic acid (pp. 1428-1436) https://doi.org/10.1021/bm034539b
  27. Venugopal et al. (2008) Interaction of cells and nanofiber scaffolds in tissue engineering (pp. 34-48) https://doi.org/10.1002/jbm.b.30841
  28. Wang et al. (2009) Electrospun nanofiber meshes with tailored architectures and patterns as potential tissue-engineering scaffolds (pp. 1-9) https://doi.org/10.1088/1758-5082/1/1/015001
  29. Wen and Tresco (2006) Effect of filament diameter and extracellular matrix molecule precoating on neurite outgrowth and Schwann cell behavior on multifilament entubulation bridging device in vitro (pp. 626-637) https://doi.org/10.1002/jbm.a.30520
  30. Yang et al. (2005) Electrospinning of nano/micro scale poly(L-lactic acid) aligned fibers and their potential in neural tissue engineering (pp. 2603-2610) https://doi.org/10.1016/j.biomaterials.2004.06.051
  31. Yu et al. (2008) Promoting neuron adhesion and growth 11(5) (pp. 36-43) https://doi.org/10.1016/S1369-7021(08)70088-9
  32. Zhang et al. (2005) Electrospinning of gelatin fibers and gelatin/PCL composite fibrous scaffolds (pp. 156-165) https://doi.org/10.1002/jbm.b.30128
  33. Zhu et al. (2008) Electrospun fibrous mats with high porosity as potential scaffolds for tissue engineering (pp. 1795-1801) https://doi.org/10.1021/bm800476u
