10.1007/s40095-021-00422-z

Energy-based performance analysis of a double pass solar air collector integrated to triangular shaped fins

HTML PDF
  • Maytham H. Machi1,
  • Maytham A. Al-Neama2,
  • J. Buzás2,
  • I. Farkas*2,
  1. Doctoral School of Mechanical Engineering, Hungarian University of Agriculture and Life Sciences, Gödöllő, HU Department of Mechanical Engineering, Faculty of Engineering, University of Kufa, Najaf, IQ
  2. Institute of Technology, Hungarian University of Agriculture and Life Sciences, Gödöllő, HU
Cover Image

Published in Issue 2021-08-31

How to Cite

Machi, M. H., Al-Neama, M. A., Buzás, J., & Farkas, I. (2021). Energy-based performance analysis of a double pass solar air collector integrated to triangular shaped fins. International Journal of Energy and Environmental Engineering, 13(1 (March 2022). https://doi.org/10.1007/s40095-021-00422-z
Crossref
Scopus
Google Scholar
Europe PMC

HTML views: 48

PDF views: 132

Abstract

Abstract In this paper, the performance of a double pass solar air collector with triangular integrated fins was investigated experimentally at Hungarian University of Agriculture and Life Sciences in Gödöllő, Hungary. The focus of this research is on energy-based performance evaluation. The thermal efficiency of the collector has been compared by testing two collectors that had the same design, with and without fins. The effect of the collector's air mass flow rate on thermal performance was investigated under various environmental situations. The results revealed that the temperature difference is always higher through the finned collector and the higher variation temperature between the inlet and outlet temperature leads to higher useful heat. The daily thermal efficiency of the finned collector was 56.57%, 59.41%, and 61.42%, while for the un-finned collector was 51.04%, 53.28%, and 57.08% for the mass flow rate 0.0081, 0.0101, and 0.0121 kg/s. The finned double pass solar air collector improved the thermal efficiency by 4.3–6.1% over the un-finned one. The efficiency of the finned collector is always higher than the un-finned one regardless of the mass flow rate. The presence of the fins to the top air channels significantly increases collector efficiency, owing to the increased absorbing surface area, which is responsible for increasing the internal thermal convective exchanges. Moreover, it creates a turbulence airflow, meaning that the air will be in good contact with the absorber plate and penetrate all regions, reducing the dead zones contributing to increased heat transfer.

Keywords

  • Solar energy,
  • Collector construction,
  • Fined absorber,
  • Thermal efficiency
HTML PDF

References

  1. Tyagi et al. (2012) Review on solar air heating system with and without thermal energy storage system (pp. 2289-2303) https://doi.org/10.1016/j.rser.2011.12.005
  2. Panwar et al. (2011) Role of renewable energy sources in environmental protection: A review (pp. 1513-1524) https://doi.org/10.1016/j.rser.2010.11.037
  3. Kalogirou (2004) Solar thermal collectors and applications (pp. 231-295) https://doi.org/10.1016/j.pecs.2004.02.001
  4. Tchinda (2009) A review of the mathematical models for predicting solar air heaters systems (pp. 1734-1759) https://doi.org/10.1016/j.rser.2009.01.008
  5. El-Sebaii et al. (2011) Thermal performance investigation of double pass-finned plate solar air heater (pp. 1727-1739) https://doi.org/10.1016/j.apenergy.2010.11.017
  6. Moummi et al. (2004) Energy analysis of a solar air collector with rows of fins (pp. 2053-2064) https://doi.org/10.1016/j.renene.2003.11.006
  7. Karim and Hawlader (2006) Performance investigation of flat plate, v-corrugated and finned air collectors (pp. 452-470) https://doi.org/10.1016/j.energy.2005.03.007
  8. Sopian et al. (2009) Evaluation of thermal efficiency of double-pass solar collector with porous-nonporous media (pp. 640-645) https://doi.org/10.1016/j.renene.2008.05.027
  9. Fudholi, A., Ruslan, M.H., Othman, M.Y., Yahya, M., Supranto, Zaharim, A., Sopian, K.: Collector efficiency of the double-pass solar air collectors with fins. Int. Conf. Syst. Sci. Simul. Eng. Proc. 428–434 (2010)
  10. Omojaro and Aldabbagh (2010) Experimental performance of single and double pass solar air heater with fins and steel wire mesh as absorber (pp. 3759-3765) https://doi.org/10.1016/j.apenergy.2010.06.020
  11. Chabane et al. (2013) Collector efficiency by single pass of solar air heaters with and without using fins (pp. 43-55) https://doi.org/10.4186/ej.2013.17.3.43
  12. Hassan and Abo-Elfadl (2018) Experimental study on the performance of double pass and two inlet ports solar air heater (SAH) at different configurations of the absorber plate (pp. 728-740) https://doi.org/10.1016/j.renene.2017.09.047
  13. Al-Neama and Farkas (2019) Thermal efficiency of vertical and horizontal-finned solar collector integrated with forced air circulation dryer for Apple as a sample (pp. 546-558) https://doi.org/10.1080/07373937.2018.1488260
  14. Mariana et al. (2014) 2013 ISES Solar World Congress thermal evaluation and modeling of a double-pass solar collector for air heating (pp. 2275-2284) https://doi.org/10.1016/j.egypro.2014.10.235
  15. Sudhakar and Cheralathan (2020) Thermal performance enhancement of solar air collector using a novel V-groove absorber plate with pin-fins for drying agricultural products: an experimental study (pp. 2397-2408) https://doi.org/10.1007/s10973-019-08952-9
  16. Velmurugan and Kalaivanan (2015) Thermal performance studies on multi-pass flat-plate solar air heater with longitudinal fins: An analytical approach (pp. 1141-1150) https://doi.org/10.1007/s13369-015-1573-5
  17. Rai et al. (2017) An analytical investigations on thermal and thermohydraulic performance of offset finned absorber solar air heater (pp. 25-40) https://doi.org/10.1016/j.solener.2017.05.039
  18. Fudholi et al. (2013) Performance and cost benefits analysis of double-pass solar collector with and without fins (pp. 8-19) https://doi.org/10.1016/j.enconman.2013.07.015
  19. Sahu and Prasad (2016) Exergy based performance evaluation of solar air heater with arc-shaped wire roughened absorber plate (pp. 233-243) https://doi.org/10.1016/j.renene.2016.04.083
  20. Scheid (1989) McGraw-Hill
  21. Bekele et al. (2014) Performance characteristics of solar air heater with surface mounted obstacles (pp. 603-611) https://doi.org/10.1016/j.enconman.2014.04.079
  22. Chabane et al. (2014) Experimental study of heat transfer coefficient with rectangular baffle fin of solar air heater (pp. 160-172) https://doi.org/10.1007/s11708-014-0321-y
  23. Karsli (2007) Performance analysis of new-design solar air collectors for drying applications (pp. 1645-1660) https://doi.org/10.1016/j.renene.2006.08.005
  24. Akpinar et al. (2010) Experimental investigation of thermal performance of solar air heater having different obstacles on absorber plates (pp. 416-421) https://doi.org/10.1016/j.icheatmasstransfer.2009.11.007
  25. Esen (2008) Experimental energy and exergy analysis of a double-flow solar air heater having different obstacles on absorber plates (pp. 1046-1054) https://doi.org/10.1016/j.buildenv.2007.02.016
